Longnose EM series drainage pickup truck
Longnose ® EM series drainage pickup truck is the first emergency rescue truck in the world which is refitted from a light duty pickup truck by extracting its engine’s power through a full-power PTO, a hydraulic system, a dual-cooling system and a smart control system to drive a vacuum assisted self priming pump and a portable submersible pump.
Longnose ® EM series drainage pickup truck is basically equipped with two sets of large flow medium head water pumps. One set is a vacuum assisted self priming pump installed inside of the cargo box, used for sewer, urban low-lying areas, underground parking garage, tunnel, underpass road as well as a place where vehicle can not reach area’s emergency drainage by connecting an anti-negative pressure hose on pump’s suction flange. The other set is a portable remote drainage pump which is stored in the cargo box, used for sewer, inland river, lake and a place where the truck parking point and drainage point has a big height difference or long distance while the vacuum assisted self priming pump can not handle area’s emergency drainage by connecting hydraulic hoses and water hose. According to different drainage scenarios, the self priming pump and the portable remote drainage pump can work independently or simultaneously.
Longnose ® series drainage pickup truck is a multi patented product both at home and abroad. It creatively combines water pumps with a pickup truck by fully utilizing vehicle’s strong power and maneuverability, and brings a completed new concept and solution for emergency rescue field. It is an ideal choice for drainage, irrigation,dredging and fire fighting.
Application
- Flood control and drainage ● Remote water supply ●Agricultural Irrigation ● Sewer Dredging.
Features
- Unique and patented Full-power PTO technology.
- All equipment are powered by truck’s engine, no additional power needed.
- Full hydraulic power output makes emergency rescue job safer.
- Self priming pump and remote pump work together to cover all drainage scenarios.
- 24*7 continuous, full load and reliable operation.
- Water pump can handle 3 inch diameter solids.
- Easy operation, convenient deployment and high maneuverability.
- Equipped with trailer hitch,brake & steering system.
Tech Data
Model |
Vacuum assisted self priming pump |
Remote pump |
||||
Flow(m3/h) |
Head (m) |
Water hose (mm) |
Flow(m3/h) |
Head (m) |
Water hose (mm) |
|
E900PK-M |
600 |
22 |
200*200 |
300 |
22 |
150*150 |
E1200PK-M |
600 |
20 |
200*200 |
600 |
20 |
200*200 |
E1600PK-M |
1000 |
15 |
250*250 |
600 |
20 |
200*200 |
